Model No.: HC43-630
Brand: gaode
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Engine, Motor, Pump
Warranty Period: 1 Year
Type Of Machine: Alligator Hydraulic Shears
Machinable Material: Brass / Copper, Alloy, Aluminum, Stainless Steel
Core Selling Point: Easy To Operate
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Applicable Industry: Hotels, Building Material Shops, Manufacturing Plant, Construction Works
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): Japan, Australia, Argentina, South Africa
Showroom Location (in Which Countries Are There Sample Rooms Overseas): Viet Nam, Argentina, Japan, Australia
Packaging: PLYWOOD CASE
Productivity: 3000 SETS/YEAR
Transportation: Ocean,Land
Place of Origin: CHINA
Supply Ability: 3000 SETS/YEAR
Certificate: CE ISO9001 SGS
HS Code: 8479819000
Port: SHANGHAI,NINGBO,NANJING
HC43-630 Hydraulic Metal Shear -- Technical Specifications
| No. | Projects | Units | Quantity |
| 1 | Maximum Shear Capability | KN | 630 |
| 2 | Maximum Pressure Capability | KN | 120 |
| 3 | Maximum Cutting Blade Opening | MM | 300 |
| 4
| Length of Cutting Blade | MM | 600 |
| 5 | Shearing times of per minutes | times/min | 9-16 |
| 6 | System Work Pressure | Mpa | 21.5Mpa |
| 7 | Motor | Model | Y132M-4 |
| Power | 7.5KW | ||
| 8 | Hydraulic Oil pump | Model | 40YCY14-1B |
| Rate of flow | 40ml/r | ||
| 9 | Size of Sheared material (mm) | Round Steel | Ø 30 |
| Square Steel | 25*25 | ||
| Steel Angle | 40*40*4 (three pcs) | ||
| Steel Channel | 100*43*5.5 | ||
| Plate | 14*100 |
Product Categories : Alligator Shear
